Table B-45. EM430F5137RF900 Bill of Materials (continued)
Item Reference
No. per
Board
Description Value
Manufacturer's Part
Number
Manufacturer Comment
24
R4-R5, R051,
R061, R431,
R441
0
UNINSTALLED RESISTOR/
JUMPER, SMT, 0402, 0 Ω, 5%,
1/16W
0Ω ERJ-2GE0R00X PANASONIC DNP
24a R7 1
RESISTOR/JUMPER, SMT,
0402, 0 Ω, 5%, 1/16W
0Ω ERJ-2GE0R00X PANASONIC
25 R2-R3, R6 3
RESISTOR, SMT, 0402, THICK
FILM, 5%, 1/16W, 330
330Ω ERJ-2GEJ331 PANASONIC
26 C431, C441 0
CAPACITOR, SMT, 0402, CER,
12pF, 50V, 5%, NPO
12pF ECJ-0EC1H120J PANASONIC
27 C401 1
CAPACITOR, SMT, 0402, CER,
2200pF, 50V, 10%, X7R
0.0022uF ECJ-0EB1H222K PANASONIC
28 R331 1
RESISTOR, SMT, THICK FILM,
56K, 1/16W, 5%
56kΩ ERJ-2GEJ563 PANASONIC
29
C081, C221,
C411, C451
4
CAPACITOR, SMT, 0603,
CERAMIC, 10uF, 6.3V, 20%, X5R
10uF ECJ-1VB0J106M PANASONIC
30 R1 1
RESISTOR/JUMPER, SMT,
0402, 0 Ω, 5%, 1/16W
0Ω ERJ-2GE0R00X PANASONIC
31 C041 0
UNINSTALLED CAP CERAMIC
4.7UF 6.3V X5R 0603
4.7uF ECJ-1VB0J475K Panasonic DNP
32 X1 1 SMA STRIGHT JACK, SMT 32K10A-40ML5 ROSENBERGER
33 Q2 0 Crystal, SMT, 32.768 kHz 32.768k MS3V-T1R Micro Crystal DNP
34 U1 1
DUT, SMT, PQFP, RGZ-48,
0.5mmLS, 7.15x7.15x1mm,
THRM.PAD
CC430F5137 TI
35 JP1 1 Pin Connector 2x4pin 61300821121 WUERTH
36 CON1-CON9 0 Pin Connector 2x4pin 61300821121 WUERTH DNP
37 JP2 1 Pin Connector 1x3pin 61300311121 WUERTH
38
JP3, JP5,
JP10
3 Pin Connector 1x2pin 61300211121 WUERTH
38a JP7, CON13 0 Pin Connector 1x2pin 61300211121 WUERTH DNP
39 JP4 1 Pin Connector 2x2pin 61300421121 WUERTH DNP
40 JP1a 1 Pin Connector 2x3pin 61300621121 WUERTH
www.ti.com Hardware
SLAU278AG – MAY 2009 – REVISED DECEMBER 2020
Submit Document Feedback
MSP430™ Hardware Tools 179
Copyright © 2020 Texas Instruments Incorporated
