Table B-20. MSP-TS430PT48A Bill of Materials (continued)
Ref Des Quantity Value Description
Package
Reference
Part Number Manufacturer
SW3, SW4,
SW5
3
Switch, DPST, Slide, Off-
On, 1 Pos, 0.15A, 30V, TH
9.65x7.12mm 78F01T Grayhill
X1 1
Crystal, 32.768 kHz,
12.5pF, SMD
1.4x1.4x5.0mm
SMD
MS3V-T1R 32.768KHZ
+/-20PPM 12.5PF
Micro Crystal AG
C8, C9 0 12pF
CAP, CERM, 12 pF, 50 V,
+/- 5%, C0G/NP0, 0805
0805 C0805C120J5GACTU Kemet
C10 0 1uF
CAP, CERM, 1 uF, 50 V,
+/- 10%, X5R, 0603
0603 GRM188R61H105KAALD MuRata
FID1, FID2,
FID3
0
Fiducial mark. There is
nothing to buy or mount.
N/A N/A N/A
J3, J4, J5,
J6
0
Header, 100mil, 12x1,
Gold, TH
12x1 Header TSW-112-07-G-S Samtec
Q1A 0 Crystal, 4 MHz, 18 pF, TH 11.5x5mm 9B-4.000MAAJ-B TXC Corporation
Q1B 0
Crystal, 32.768 kHz,
12.5pF, SMD
1.4x1.4x5.0mm
SMD
MS3V-T1R 32.768KHZ
+/-20PPM 12.5PF
Micro Crystal AG
R4, R8, R9 0 0
RES, 0, 5%, 0.333 W,
AEC-Q200 Grade 0, 0805
0805 CRCW08050000Z0EAHP Vishay-Dale
R13 0 47k
RES, 47 k, 5%, 0.125 W,
AEC-Q200 Grade 0, 0805
0805 CRCW080547K0JNEA Vishay-Dale
TP1, TP2,
TP3, TP4,
TP5, TP6
0
Test Point, Miniature,
Black, TH
Black Miniature
Testpoint
5001 Keystone
www.ti.com Hardware
SLAU278AG – MAY 2009 – REVISED DECEMBER 2020
Submit Document Feedback
MSP430™ Hardware Tools 91
Copyright © 2020 Texas Instruments Incorporated
