BODY
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
23
Repair and Service Manual
647701
Figure 20 Seat Support and Floorboard
Tighten the screws (44, 46) to the torque value specified
below.
Figure 21 Bagwell Closeout
Bagwell Closeout
Tool List Qty.
Notched Pry Bar .......................................................... 1
Remove the ratchet rivets (49). Remove the bagwell
closeout (50) (Figure 21).
Installation is in the reverse order of removal. Replace
any worn or damaged hardware.
BODY CARE MAINTENANCE
Cleaning
Tools and Supplies List Qty.
Soft Clean Cotton Cloth...............................................1
Mild Soap.................................................................A/R
The body panels are painted and have a clear coat finish
applied.
For a light cleaning, spray the vehicle with a mist of water
and wipe clean with a soft cotton cloth.
1. Spray the body with a low pressure hose to rinse off
any loose dust and dirt.
2. Wash the vehicle with a solution of mild soap and
water using a soft cotton cloth. Do not use abrasive
cleaners or solvents.
Apply clear coat safe automotive car wax to revive lost
luster as needed.
Test the wax on an inconspicuous area before
applying to the entire vehicle. Buff the wax by hand.
Do not use a power buffer to remove wax from the
body panels.
PAINTING
Follow the paint manufacturer’s recommendations for
specific painting procedures and information.
All painting must be done in an area with ade-
quate ventilation to safely disperse harmful
vapors.
Wear eye protection and a respirator to protect
from overspray and airborne mist.
Provide protection from overspray to vehicle and
surrounding area.
Item Torque Specification
44, 46 13 - 16 ft. lbs. (18 - 22 Nm)
