FUEL SYSTEM
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
69
FUEL TANK REMOVAL
Tool List Qty.
Wrench, 5/16”.............................................................. 1
Socket, 5/16” ............................................................... 1
Ratchet........................................................................ 1
Drip Pan ...................................................................... 1
Insulated wrench, 1/2”................................................. 1
Wear eye protection. Disconnect the negative (-) battery
wire. Turn off the fuel shut off valve (15). Disconnect the
fuel line (17) at the fuel pickup and the line to the CARB
canister, Always monitor for fuel leakage from the fuel
line. Always use a drip pan and dispose of spent fuel
safely.
Remove bolt (33) and washer (32). Remove screw (31)
and washer (32). Remove the tank.
Installation is in reverse order of removal.
CARBON CANISTER
Tool List Qty.
Flat Blade Screwdriver ................................................ 1
To remove the CARB canister (7), disconnect hoses (6, 8)
from the cannister, press the tabs on the mounting
bracket and lift upward on the canister.
To install a CARB canister (7), position the canister ears
above the mounting bracket (2) and push against the
bracket (2) and downward so that the canisters ears slide
into the channels on the bracket. Make sure that the can-
ister is seated completely and the retaining tabs are clear
of the canister ears. Connect the hoses.
Item Torque Specification
33 97 - 132 in. lbs (11 - 15 Nm)
31 26 - 44 in. lbs (3 - 5 Nm)
