WHEELS AND TIRES
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
For models with a 1/4” wheel spacer, reinstall spacer
before installing wheel/tire.
With the valve stem to the outside of wheel, install the
wheel onto the hub with lug nuts.
Finger tighten lug nuts (1) in the cross sequence pattern
as shown (Figure 1). Continue to tighten the lug nuts in 20
ft. lbs. (27 Nm) increments to the torque value specified
below.
Continue to follow the cross-sequence pattern until the
correct torque is reached.
Figure 1 Wheels and Tires
Item Torque Specification
1 50 - 85 ft. lbs. (68 - 115 Nm)
*VSRXSJ:ILMGPI
'VSWW7IUYIRGI
8MVI7X]PI1E]:EV]

:EPZIWXIQWLSYPHEP[E]W
FIXSSYXWMHISJXLI[LIIP
%P[E]WVITPEGIXLIZEPZIWXIQGET
:EPZI7XIQ
'ET
 
 
