Sample mapping for two samples per subarray
Sample 48
Sample 96
Sample 1
Sample 49
Sample Plate
Sample 1
Load 1
Sample 48
Sample 49
Load 2
Sample 96
Subarray D12
Subarray A1
OpenArray Plate
Figure 10 Example sample mapping for two samples per subarray
Chapter 5 Map plates
Configure the experiment design to map the plates
