Topcon MACHINE CONTROL AG System Five - Page 18

Introduction and Setup
Topcon AG System Five Operator’s Manual
1-6
1. Attach the Laser Receiver to the TM-1 mast (Figure 1-6).
Figure 1-6. Attaching Laser Receiver to TM-1 Mast
MOUNTING
KNOB
MOUNTING
BRACKET
LS-B2
Tighten
Mounting Kno
b
S
lide Laser Receiver
D
own onto Mast
1
2
