Topcon MACHINE CONTROL AG System Five - Page 89

Serpentine Survey
P/N 7010-0369 www.topconpositioning.com
4-11
Figure 4-10. Serpentine Survey
NOTICE
Record elevations only when crossing the field,
not when turning at its border.
Recording elevations while turning will skew the
results of your survey.
When crossing the field, maintaining a consistent speed from one
side to the next will give you a uniform and accurate survey. Use the
survey method you are most comfortable with, or follow the steps
below:
1. Enter the desired field slope, or the calculated slope, into the
laser transmitter. This slope determines the slope of the field
when finished land-leveling.
2. With the Control Box in Survey mode, press and hold the
ELEV/AVG button for three seconds to clear any previous
readings.
3. Begin driving the field in a serpentine pattern with the scraper
just “floating” on the ground, maintaining a constant speed.
S
t
op
&
A
ve
r
a
g
e
E
l
eva
t
ion
s
A
t
E
nd
o
f
E
ac
h
L
e
g
D
O
N
OT
S
u
r
vey
T
h
r
ough
T
u
r
n
s
S
u
r
vey
A
c
r
o
ss
F
i
e
ld
f
o
r
E
ac
h
L
e
g
.
05
%
.
075
%
100
'
t
o
200
'
