33
PREPARATIONS
Setting of auto small pupil selector function
Set the auto small pupil selector function ON/OFF. (Factory default is "ON".)
The auto small pupil selector function works as follows: when the pupil diameter of the patient
is too small to take a picture, the instrument automatically changes to the small pupil dia-
phragm.
1 On the "MENU" screen, make sure that "AUTO" is selected and press the .
2 Press the or to select "SMALL
PUPIL" and then press the .
3 Select "ON" or "OFF" with the or
and then press the . The selected data is set.
ENTER SWITCH
DOWNWARD CURSOR SWITCH
UPWARD CURSOR SWITCH
ENTER SWITCH
MENU
ON
FIXATION
FLASH
SMALL PUPIL
OFF
FOCUS
SHOOT
MEMORY
*The above figure shows the screen of TRC-NW8F.
DOWNWARD CURSOR SWITCH
UPWARD CURSOR SWITCH
ENTER SWITCH
MENU
ON
FIXATION
FLASH
SMALL PUPIL
OFF
FOCUS
SHOOT
MEMORY
*The above figure shows the screen of TRC-NW8F.
