Introduction
3DExcavatorIndicateSystems
4
X‐63/X‐63i/X‐62/X‐33/X‐32InstallationandCalibrationManual P/N:7010‐0697
X-63i
Figure5showsthebasiccablingconnectionsfortheX‐63isystem.Wheninstallingcomponents,use
theTopconsuppliedfuseorfusedpowerfromthemachineofthesamerating.
Figure5:BasicCableConnectionsfortheX‐63iSystem
Systemgroundmustbeconnectedtotheframesideofthegrounddisconnectswitch,not
directlytotheneg ativebatteryterminal.
Main
GPS
Antenna
Aux
GPS
Antenna
MC-i3
GX-60
Optional
Lightbar
TS-1 Tilt Sensors
StickBoomBody Bucket
7.5 Amp In-line Fuse Required
Sensor
Terminator
Radio
Antenna
