Introduction
3DExcavatorIndicateSystems
6
X‐63/X‐63i/X‐62/X‐33/X‐32InstallationandCalibrationManual P/N:7010‐0697
X-33
Figure7showsthebasiccableconnectionsfortheX‐33system. Wheninstallingcomponents,usethe
Topconsuppliedfuseorfusedpowerfromthemachineofthesamerating.
Figure7:BasicCableConnectionsfortheX‐33System
Systemgroundmustbeconnectedtotheframesideofthegrounddisconnectswitch,not
directlytotheneg ativebatteryterminal.
Main
GPS
Antenna
Aux
GPS
Antenna
MC-i3
GX-30
Radio
Antenna
Serial
CAN
TS-i3 Tilt Sensors
StickBoomBody Bucket
External
Radio
Modem
7.5 Amp In-line Fuse Required
