Dimensions and Weights
CLCH-SVX07K-EN 13
Section Dimensions and Weights
Table 5. Section dimensions (inches) and weights (pounds) — unit sizes 3 to 30
Nominal airflow
1
1500 2000 3000 4000 5000 6000 7000 8500 10,500 12,500 15,000
Airflow at 625 fpm
2
2169 3475 4338 4581 6075 8331 9025 11,806 13,456 16,944 19,025
Unit size
3 4 6 8 10 12 14 17 21 25 30
Height - indoor unit
3
29.00 29.00 35.25 37.75 37.75 41.50 41.50 49.00 52.75 61.50 61.50
Width 31.50 44.00 44.00 50.50 61.50 66.50 72.00 72.00 80.00 80.00 93.50
Height for outdoor unit
includes base drip lip
4
36.25 36.38 42.63 45.13 45.13 49.25 49.25 56.75 60.50 69.25 69.25
Weight add for outdoor unit
(lbs/in. of unit length)
1.66 1.91 1.91 2.04 2.27 2.40 2.51 2.51 2.68 2.68 2.94
Access or blank
5
-Small horizontal
10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00
48.05 57.43 60.55 66.67 74.92 80.55 84.67 88.41 96.28 100.65 110.78
-Medium horizontal
14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00
59.91 71.18 75.25 82.74 92.66 99.61 104.57 109.45 119.10 124.79 136.97
-Extended-medium
horizontal
19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00
74.73 88.37 93.62 102.82 114.83 123.43 129.44 135.74 147.62 154.97 169.71
-Medium-large horizontal
24.50 24.50 24.50 26.50 26.50 26.50 26.50 24.50 24.50 24.50 24.50
121.60 107.28 113.84 132.94 148.08 159.18 166.74 164.66 178.99 188.17 205.72
-Large horizontal or turning
34.00 34.00 34.00 36.00 36.00 36.00 36.00 36.00 34.00 46.00 46.00
137.75 164.85 179.46 208.50 235.01 257.70 271.35 293.42 314.60 413.45 457.18
-Extra-large horizontal or
turning
36.00 41.00 41.00 44.00 42.50 42.50 42.50 44.00 50.25 56.50 56.50
143.68 188.92 205.18 240.63 263.83 288.68 303.68 335.49 407.29 476.83 525.93
-Ducted inlet or ducted
outlet section
10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00
48.10 57.40 60.50 66.70 74.90 80.50 84.70 88.40 96.30 100.60 110.80
Blender
19.00 24.50 24.50 26.50 36.00 36.00 36.00 36.00 34.00 46.00 46.00
94.86 132.71 146.30 173.34 238.64 264.12 276.73 303.71 323.59 427.13 470.25
Cool Dry Quiet (CDQ)
Desiccant Dehumidification
52.00 52.00 52.00 52.00 55.00 58.00 58.00 58.00 56.00 56.00 58.00
495.00 651.00 694.00 792.00 1011.00 1165.00 1326.00 1390.00 1793.00 1876.00 2029.00
Coils
-Small horizontal
(with 4-row UW)
10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00
116.10 148.55 174.35 205.79 244.49 285.13 307.44 352.47 433.37 502.46 572.50
-Medium horizontal
(with 8-row UW)
14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00
168.65 220.23 265.58 318.97 382.53 450.07 488.32 569.79 700.27 817.63 941.48
-Extended-medium
horizontal (with 8-row UW)
19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00
185.58 239.53 286.06 341.16 406.80 476.00 516.35 599.24 737.96 858.03 985.30
-Medium-large horizontal
(with 10-row W)
24.50 24.50 24.50 26.50 26.50 26.50 26.50 24.50 24.50 24.50 24.50
270.61 359.79 433.08 554.88 656.63 777.26 884.93 1013.57 1262.10 1478.66 1503.93
-Large horizontal or vertical
(with 10-row W)
34.00 34.00 34.00 36.00 36.00 36.00 36.00 36.00 34.00 46.00 46.00
302.77 396.45 471.99 597.03 702.74 826.53 938.18 1081.30 1333.70 1652.36 1652.73
