Trane CSAA User Manual

Component Installation
64 CLCH-SVX07K-EN
Table 17. Standard Traq damper - low flow Traq damper
Unit
size
Damper
dia (in)
Damper
qty per
face
Damper
torque
(in-lb.)
Std Traq
damper
torque
(in-lb.)
Linked low
flow Traq
damper
torque
(in-lb.)
Actuator
torque
(max)
(in-lb.)
Actuator
qty for
linked Std
Traq
Damper
Actuator
qty for
linked low
flow Traq
damper
Actuator
qty for
single low
flow Traq
damper
Face-
to-face
linkage
Linkage
on face
Total
actuator
qty
6 13.00 2 18.0 36.0 18.00 42 1 - 2 No Yes 3
8 13.00 3 18.0 54.0 36.00 180 1 1 1 No Yes 3
10 13.00 3 18.0 54.0 36.00 180 1 1 1 No Yes 3
12 16.00 3 22.5 67.5 45.00 180 1 1 1 No Yes 3
14 16.00 3 22.5 67.5 45.00 180 1 1 1 No Yes 3
17 16.00 3 22.5 67.5 45.00 180 1 1 1 No Yes 3
21 20.00 3 33.0 99.0 66.00 180 1 1 1 No Yes 3
25 20.00 3 33.0 99.0 66.00 180 1 1 1 No Yes 3
30 24.00 3 36.0 108.0 72.00 180 1 1 1 No Yes 3
35 24.00 3 36.0 108.0 72.00 180 1 1 1 No Yes 3
40 24.00 3 36.0 108.0 72.00 180 1 1 1 No Yes 3
50 28.00 3 37.5 112.5 75.00 180 1 1 1 No Yes 3
57 28.00 3 37.5 112.5 75.00 180 1 1 1 No Yes 3
66 28.00 4 37.5 150.0 112.50 180 1 1 1 No Yes 3
80 28.00 5 37.5 187.5 150.00 180 2 1 1 No Yes 4
100 28.00 6 37.5 225.0 187.5 180 2 2 1 No Yes 5
120 28.00 6 37.5 225.0 187.5 180 2 2 1 No Yes 5
Table 18. Side Traq damper - standard flow mixing box
Unit size
Damper dia
(in)
Damper
qty
Damper torque
(in-lb)
Total torque
(in-lb)
Actuator
torque (max)
(in-lb)
Actuator
qty
Face-to-face
linkage
Linkage on
face
3, 4, 6, 8 13.00 1 18.00 18.00 42.00 1 No No
10, 12 16.00 1 22.50 22.50 42.00 1 No No
14, 17 13.00 2 18.00 36.00 42.00 1 No Yes
21, 25 16.00 2 22.50 45.00 180.00 1 No Yes
30, 35, 40 20.00 2 33.00 66.00 180.00 1 No Yes
50, 57, 66 24.00 2 36.00 72.00 180.00 1 No Yes
80 28.00 2 37.50 75.00 180.00 1 No Yes
100 28.00 3 37.50 112.50 180.00 1 No Yes
120 24.00 4 36.00 144.00 180.00 1 No Yes
