Component Installation
CLCH-SVX07K-EN 69
Table 27. Energy recovery bypass opposed-blade damper
Unit size A (in) B (in)
Damper
qty
Torque
(in-lb.)
Actuator Torque
(max) (in-lb.)
Actuator
qty Linkage
3 - 8 18.00 8.22 1 5.10 42.00 1 No
8 - 14 32.00 8.22 1 9.10 42.00 1 No
10 - 17 41.75 8.22 1 11.90 42.00 1 No
12 - 21 53.50 8.22 1 15.30 42.00 1 No
21 - 50 52.50 13.97 1 25.50 180.00 1 No
17, 21 61.50 8.22 1 17.60 42.00 1 No
21 - 30 66.00 8.22 1 18.80 42.00 1 No
25 - 50 65.00 13.97 1 31.50 180.00 1 No
21 70.00 8.22 1 20.00 42.00 1 No
35 - 50 84.50 13.97 1 41.00 180.00 1 No
35 - 50 75.00 13.97 1 36.40 180.00 1 No
40 - 50 102.00 13.97 1 49.50 180.00 1 No
50 113.00 13.97 1 54.80 180.00 1 No
Table 28. Exhaust fan damper torque
Unit size A (in) B (in)
Damper
Qty
Torque
(in-lb.)
Actuator Torque
(max) (in-lb.)
Actuator
qty Linkage
3 19.83 13.97 1 13.50 42.00 1 No
4 32.33 13.97 1 22.00 42.00 1 No
6 32.33 13.97 1 22.00 42.00 1 No
8 38.83 13.97 1 26.40 180.00 1 No
10 49.83 13.97 1 33.80 180.00 1 No
12 54.83 13.97 1 37.20 180.00 1 No
14 60.33 13.97 1 41.00 180.00 1 No
17 60.33 13.97 1 41.00 180.00 1 No
21 68.33 13.97 1 46.40 180.00 1 No
25 68.33 13.97 1 46.40 180.00 1 No
30 81.83 13.97 1 55.60 180.00 1 No
35 40.88 19.72 2 78.40 180.00 2 No
40 30.42 19.72 3 87.50 180.00 3 No
50 34.75 19.72 3 99.90 180.00 3 No
57 34.75 19.72 3 99.90 180.00 3 No
66 39.75 31.22 3 181.00 180.00 3 No
80 38.42 31.22 3 174.90 180.00 3 No
100 43.09 31.22 3 196.20 180.00 3 No
120 52.25 31.22 3 237.90 180.00 3 No
