Trane CSAA User Manual

Component Installation
66 CLCH-SVX07K-EN
Table 22. Side Traq low-flow diagonal economizer
Unit
size
D a mp e r
dia (in)
Damper
qty
D a m p er
torque
(in-lb.)
Low flow
Traq torque
(in-lb.)
Remainder
Traq torque
(in-lb.)
Actuator
qty for low
flow Traq
Actuator qty
for remainder
damper
Actuator
total qty
Face-to-
face
linkage
Linkage
on face
6 13.00 2 18.00 18.00 18.00 1 1 2 No No
8 13.00 2 18.00 18.00 18.00 1 1 2 No No
10 16.00 2 22.50 22.50 22.50 1 1 2 No No
12 16.00 2 22.50 22.50 22.50 1 1 2 No No
14 16.00 2 22.50 22.50 22.50 1 1 2 No No
17 13.00 4 18.00 18.00 54.00 1 1 2 No Yes
21 20.00 2 33.00 33.00 33.00 1 1 2 No No
25 16.00 4 22.50 22.50 67.50 1 1 2 No Yes
30 20.00 3 33.00 33.00 66.00 1 1 2 No Yes
35 28.00 2 37.50 37.50 37.50 1 1 2 No No
40 28.00 2 37.50 37.50 37.50 1 1 2 No No
50 24.00 3 36.00 36.00 72.00 1 1 2 No Yes
57 24.00 4 36.00 36.00 108.00 1 1 2 No Yes
66 28.00 3 37.50 37.50 75.00 1 1 2 No Yes
80 28.00 4 37.50 37.50 112.50 1 1 2 No Yes
100 28.00 5 37.50 37.50 150.00 1 1 2 No Yes
120 28.00 5 37.50 37.50 150.00 1 1 2 No Yes
Table 23. Side rectangle angle damper - 2000 fpm
Unit size A (in) B (in)
Damper
qty
Torque
(in-lb.)
Actuator torque
(max) (in-lb.)
Actuator
qty Linkage
3 11.25 13.97 1 13.10 42.00 1 No
4 11.25 13.97 1 13.10 42.00 1 No
6 15.75 13.97 1 18.30 42.00 1 No
8 20.25 13.97 1 23.60 42.00 1 No
10 20.25 16.30 1 27.50 42.00 1 No
12 27.00 16.30 1 36.70 42.00 1 No
14 23.25 19.72 1 38.20 42.00 1 No
17 30.50 19.72 1 50.10 180.00 1 No
21 36.75 19.72 1 60.40 180.00 1 No
25 45.75 19.72 1 75.20 180.00 1 No
30 48.50 20.22 1 81.70 180.00 1 No
35 45.50 25.47 1 96.60 180.00 1 No
40 48.00 28.35 1 113.40 180.00 1 No
50 56.75 31.22 1 147.60 180.00 1 No
57 65.75 31.22 1 171.10 180.00 1 No
66 70.50 31.22 1 183.40 180.00 2 No
80 85.00 31.22 1 221.10 180.00 2 No
100 95.00 36.97 1 292.70 180.00 2 No
120 96.00 42.72 1 341.80 180.00 2 No
