Routine Maintenance
CLCH-SVX07K-EN 149
2. Support wheel with wooden blocks on both sides of the
wheel.
3. Make sure the wheel is secure. The short posts are
removed first.
4. To prevent wheel from flipping out, cut two 1-inch x 4-
inch boards for placement across the face and behind
the lip and corner braces on the cassette.
5. Remove the post mounting screws or bolts at both
ends of the long post.
6. Remove the shaft bolt.
Figure 172. Wooden blocks support wheel
Figure 173. Remove short posts first
Figure 174. Prevent wheel from flipping out with boards
Figure 175. Remove post mounting screws
Figure 176. Remove shaft bolt
