Dimensions and Weights
22 CLCH-SVX07K-EN
Fans/Motors
Note: Trane has a Precision Motor™ option for direct-
drive plenum fans. This offering takes a general
purpose motor and re-rates the motor for higher
rated loads. This maximizes part-load motor
efficiency and precisely sizes the motor for the
application. To use these tables, the nameplate hp
of the motor and the VFD—both of which will be
greater than the Precision Motor hp—must be
known.
Starter/VFD Weights
With the exception of motorized impellers, fan weight
does not include starter/VFD weight. See Table 7 for
approximate starter/VFD weight.
Motor Weights
Fan weights provided in this manual include the heaviest
ODP (open drip-proof) motor. In the case of motorized
impellers, fan weights include the packaged motor.
Table 7. Approximate starter and VFD weights per horsepower (lbs.)
Horsepower 1 1 1/2 2 3 5 7 1/2 10 15 20 25 30 40 50 60 75 100 125
Starter
1
65 65 65 65 65 65 65 65 65 97 97 97 97 97 97 97 97
VFD
2
123 123 132 124 125 136 151 162 177 197 241 325 332 243 258 294 314
Note:
1
These weights represent the largest available starter.
2
VFD weights include transformer, distribution block, and enclosure.
Table 8. Approximate motor weights (pounds)
Motor Type
Motor
RPM
Horsepower
3/4 1 1-1/2 2 3 5 7-1/2 10 15 20 25 30 40 50 60 75 100 125
Energy efficient ODP (EEOP) 1800 24 29
NEMA Premium ODP (HEOP)
1200
39 77 91 147 126 249 300 375 443 594 667
NEMA Premium TEFC (HETC) 56 96 109 148 185 310 341 423 481 614 655
NEMA Premium ODP (HEOP)
1800
36 42 47 76 82 118 148 234 263 330 379 488 521 698 808 1114 1238
NEMA Premium TEFC (HETC) 47 54 56 91 108 159 185 285 315 452 481 578 670 808 889 1239 1466
NEMA Premium ODP (HEOP)
3600
36 36 37 89 104 173 203 267 243 261 407
NEMA Premium TEFC (HETC) 36 53 62 85 103 154 176 287 322 448 496
