Trane CSAA User Manual

Dimensions and Weights
CLCH-SVX07K-EN 21
Unit size
35 40 50 57 66 80 100 120
Mixing box
-with angled filters
48.00 48.00 48.00 48.00 49.00 54.00 60.00 60.00
519.12 561.92 653.36 653.36 946.02 1077.83 1287.99 1433.55
-with front/back Traq and top
Traq dampers
63.75 63.75 68.50 68.50 84.00 92.00 96.00 96.00
966.49 1073.80 1261.78 1365.59 1907.28 2151.42 2473.12 2790.48
-reduced length with side/
top/back/bottom airfoil
damper
35.50 38.50 41.50 41.50 41.50 41.50 47.00 53.00
708.50 795.10 947.60 1022.70 1328.50 1453.60 1731.30 2025.40
Multizone
9
- 2-deck vertical discharge
88.00 88.00 88.00
n/a n/a n/a n/a n/a
1730.00 1878.00 2289.00
-1-deck vertical discharge
79.50 79.50 79.50
n/a n/a n/a n/a n/a
1075.00 1150.00 1310.00
Silencer
-3 ft
38.00 38.00 38.00 38.00 38.00 38.00 38.00 38.00
918.00 974.00 1226.00 1332.00 1573.00 1741.00 2196.00 2555.00
-5 ft
62.00 62.00 62.00 62.00 62.00 62.00 62.00 62.00
1335.00 1439.00 1795.00 1945.00 2313.00 2555.00 3230.00 3786.00
Trane Catalytic Air
Cleaning System
(TCACS)
36.00 36.00 36.00 36.00 36.00 36.00 36.00 36.00
881.59 935.35 1044.28 1148.17 1362.38 1451.30 1707.27 1881.13
UV light
14.00 14.00 14.00 14.00 15.00 15.00 15.00 15.00
325.48 352.71 394.34 419.43 574.52 604.11 667.60 758.72
Diagonal economizer
-with airfoil dampers
75.00 83.00 72.00 76.00 83.00 86.00 93.00 93.00
931.00 1062.00 1120.00 1223.00 1680.00 1851.00 2173.00 2396.00
-with airfoil damper and one
side Traq damper
75.00 83.00 72.00 76.00 83.00 86.00 93.00 93.00
973.00 1101.00 1169.00 1266.00 1722.00 1920.00 2290.00 2494.00
Exhaust damper section
24.50 24.50 24.50 22.40 22.40 22.40 22.40 22.40
450.80 489.90 565.60 586.60 755.30 820.10 935.50 1058.30
Hoods
-Back inlet hood with
moisture eliminator - airfoil
and Traq dampers
99.88 112.38 125.38 125.38 126.00 140.00 140.00 167.25
175.86 195.13 229.85 269.82 317.00 344.00 491.00 566.00
-Side inlet hood with moisture
eliminator - airfoil and Traq
dampers
40.88 40.88 44.75 37.25 37.25 37.25 43.00 48.75
122.04 128.02 160.97 174.27 189.00 258.00 412.00 415.00
-Exhaust hood - airfoil
damper
40.88 40.88 39.63 37.25 37.25 37.25 43.00 48.75
72.80 76.89 92.81 113.92 129.00 174.00 206.00 221.00
-Economizer inlet hood with
moisture eliminator
75.00 83.00 72.00 75.50 83.00 86.00 93.00 93.00
194.99 274.95 358.02 345.28 418.35 522.34 629.31 778.43
Pipe cabinet weight
15 in. long, 36 in. deep 175.00 175.00 191.00 209.00 215.00 243.00 265.00 265.00
24 in. long, 36 in. deep 199.00 199.00 216.00 236.00 243.00 273.00 298.00 298.00
48 in. long, 36 in. deep 263.00 263.00 284.00 309.00 317.00 354.00 385.00 385.00
96 in. long, 36 in. deep 392.00 392.00 421.00 454.00 466.00 517.00 558.00 558.00
Notes:
1
Nominal airflow is based on 500 fpm through a nominal coil (i.e. 500xunit size 8=4000 cfm).
2
Airflow@625 fpm through the flat filter (maximum
filter velocity).
3
Height includes standard 2.5-inch base frame for sizes 3-57 and 6-inch base frame for sizes 66-120.
4
Height includes 6-inch base
frame for sizes 3-120.
5
Variable lengths available from 14-96 inches.
6
Nominal length and height shown for discharge plenums. Variable plenum
height and length is available from 0.5 to 1.5 of nominal.
7
Fan section weights include the heaviest fan with the largest ODP motor available.
8
Access section required with humidifiers for dispersion distance.
9
Multizone weight does not include cooling coil on lower deck.
Table 6. Section dimensions (inches) and weights (pounds) - unit sizes 31-120
