Trane CSAA User Manual

Dimensions and Weights
20 CLCH-SVX07K-EN
Unit size
35 40 50 57 66 80 100 120
Filters
-Side load 2-in. angled
24.50 24.50 27.50 27.50 27.50 27.50 27.50 27.50
593.86 649.06 770.02 797.89 989.00 1088.02 1157.16 1282.20
-Side load 4-in. angled
24.50 24.50 27.50 27.50 27.50 27.50 27.50 27.50
594.02 631.64 768.20 805.97 999.89 1105.14 1201.91 1338.65
-Side load cartridge 12-in. or
short bag 18-in.
24.50 24.50 27.50 27.50 27.50 27.50 27.50 27.50
681.24 668.25 878.57 934.14 1239.99 1364.91 1746.31 1903.54
-Side load 2-in. flat
14.00 14.00 14.00 14.00 15.00 15.00 15.00 15.00
319.66 358.18 408.69 438.52 598.12 637.02 716.56 817.63
-Side load 4-in. flat
14.00 14.00 14.00 14.00 15.00 15.00 15.00 15.00
359.20 375.13 451.33 498.71 657.87 729.15 803.46 913.90
Filters
-Side load 2-in. and 4-in.
combination flat
19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00
476.00 504.37 600.40 671.64 853.08 981.02 1078.09 1165.92
-Side-load long bag 30-in.
37.25 37.25 37.25 37.25 37.25 37.25 37.25 37.25
657.41 716.04 826.72 906.56 1094.61 1270.51 1393.17 1549.80
-Front-load HEPA
40.00 40.00 40.00 40.00 40.00 40.00 40.00 40.00
985.62 1128.46 1397.21 1520.35 1845.81 2141.38 2553.97 2924.72
-Front-load cartridge
40.00 40.00 40.00 40.00 40.00 40.00 40.00 40.00
867.68 922.78 1093.06 1173.89 1449.48 1671.46 1923.09 2155.95
-Front-load short bag
45.00 45.00 45.00 45.00 45.00 45.00 45.00 45.00
750.89 799.75 917.08 979.84 1231.49 1365.35 1538.95 1696.33
Gas Heat — Drum and Tube
- 200 MBH n/a n/a n/a n/a n/a n/a n/a n/a
- 300 MBH n/a n/a n/a n/a n/a n/a n/a n/a
- 320/360 MBH
66.00
n/a n/a n/a n/a n/a n/a n/a
1402.11
- 560 MBH
66.00 64.00 64.00 64.00 n/a n/a n/a n/a
1594.61 1468.07 1853.53 1900.53 n/a n/a n/a n/a
- 700 MBH
73.00 75.00 74.00 74.00 74.00
n/a n/a n/a
1895.19 1804.11 2190.52 2241.91 2490.63
- 860 MBH
80.00 75.00 74.00 74.00 74.00 74.00 n/a n/a
2046.29 2098.72 2280.52 2331.91 2580.63 2198.81 n/a n/a
- 1000 MBH
80.00 81.00 77.00 77.00 74.00 74.00 84.00 92.00
1723.73 1844.68 2325.57 2082.86 2300.63 1918.81 3156.04 3125.34
- 1250-1750 MBH
101.00 105.00 106.00 106.00 109.00 109.00 92.00 102.00
2540.84 2717.94 3264.84 2942.76 3309.39 2949.68 3878.54 3886.60
- 2000 MBH n/a n/a
114.00 114.00 112.00 112.00 109.00 109.00
3758.71 3430.29 3688.33 3320.33 4503.52 4391.21
-2400 MBH n/a n/a n/a n/a
118.00 112.00 121.00 119.00
3890.31 3455.33 4715.85 4668.51
Humidifier
8
-Building steam
14.00 14.00 14.00 14.00 15.00 15.00 15.00 15.00
544.00 599.00 782.00 897.00 1123.00 1215.00 1363.00 1551.00
-Atmospheric seam
19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00
581.00 665.00 724.00 803.00 977.00 1078.00 1265.00 1492.00
Table 6. Section dimensions (inches) and weights (pounds) - unit sizes 31-120
