General Information
CLCH-SVX07K-EN 7
sequencing, Trane Graphic Programming (TGP) and Rover
set-up files for the specific unit selected. These resources
are available through your local Trane sales office.
For more information on controls, refer to the following
manuals:
• Programmable UC600 controllers
– BAS-SVX45*-EN, Installation, Operation, and
Maintenance Tracer UC600 Programmable
Controller
– X39641178-01D, UC600 Installation Instructions
– X39641191-01A, Installing the Tracer TD7 Display
– BAS-SVX50*-EN, Tracer TD7 Display for the Tracer
UC600 Programmable Controller Installation,
Operation, and Maintenance Guide
• TR150 Drives
– BAS-SVX59*-EN TR150 Design Guide
– BAS-SVP16*-EN TR150 Programming Guide
Wiring
Entrances are generally provided for field-installation of
high and low voltage wiring through a pipe/nipple
connection in the unit depending on unit configuration
with or without factory-mounted controls. Before
installation, consider overall unit serviceability and
accessibility before mounting, running wires (power),
making penetrations, or mounting any components to the
cabinet.
Wiring to the air handler must be provided by the installer
and must comply with all national and local codes. The fan
motor nameplate includes a wiring diagram. If there are
any questions concerning the wiring of the motor, write
down the information on the motor nameplate and contact
your local Trane sales office.
WARNING
Proper Field Wiring and Grounding
Required!
Failure to follow code could result in death or serious
injury. All field wiring MUST be performed by qualified
personnel. Improperly installed and grounded field
wiring poses FIRE and ELECTROCUTION hazards. To
avoid these hazards, you MUST follow requirements for
field wiring installation and grounding as described in
NEC and your local/state electrical codes.
