Trane CSAA User Manual

Component Installation
CLCH-SVX07K-EN 65
Table 19. Side Traq damper - standard flow diagonal economizer
Unit
sizes
Damper
dia (in)
D a m p e r
qty
Damper
torque (in-lb.)
Total torque
(in-lb.)
Actuator torque
(max) (in-lb.)
Actuator
qty
Face-to-face
linkage
Linkage on
face
3 13.00 1 18.00 18.00 42.00 1 No No
4 13.00 2 18.00 36.00 42.00 2 No No
6, 8 13.00 2 18.00 36.00 42.00 1 No Yes
10, 12, 14 16.00 2 22.50 45.00 180.00 1 No Yes
17 13.00 4 18.00 72.00 180.00 1 No Yes
21 20.00 2 33.00 66.00 180.00 1 No Yes
25 16.00 4 22.50 90.00 180.00 1 No Yes
30 20.00 3 33.00 99.00 180.00 1 No Yes
35 28.00 2 37.50 37.50 42.00 2 No No
40 28.00 2 37.50 75.00 180.00 1 No Yes
50 24.00 3 36.00 108.00 180.00 1 No Yes
57 24.00 4 36.00 144.00 180.00 1 No Yes
66 28.00 3 37.50 112.50 180.00 1 No Yes
80 28.00 4 37.50 150.00 180.00 1 No Yes
100, 120 28.00 5 37.50 187.50 180.00 2 No Yes
Table 20. Single -Side Traq low flow mixing box
Unit size
Damper
Dia (in)
Damper
Qty
Damper
Torque
(in-lb.)
Low flow
Traq
Torque (in-
lb.)
Remained
Traq Torque
(in-lb.)
Actuator
qty for low
flow Traq
Actuator qty
for
remained
damper
Actuator
total Qty
Face-to-
face
Linkage
Linkage
on Face
14, 17 13.00 2 18.00 18.00 18.00 1 1 2 No No
21, 25 16.00 2 22.50 22.50 22.50 1 1 2 No No
30, 35, 40 20.00 2 33.00 33.00 33.00 1 1 2 No No
50, 57, 66 24.00 2 36.00 36.00 36.00 1 1 2 No No
80 28.00 2 37.50 37.50 37.50 1 1 2 No No
100 28.00 3 37.50 37.50 75.00 1 1 2 No Yes
120 24.00 4 36.00 36.00 108.00 1 1 2 No Yes
Table 21. Dual-side Traq low flow mixing box
Unit size
Damper
dia (in)
Damper
qty
Damper
torque
(in-lb)
Low-flow
Traq
torque
(in-lb)
Remained
Traq
torque
(in-lb)
Actuator
qty for
std Traq
damper
Actuator qty
for low-flow
Traq
damper
Actuator
qty for
single low-
flow Traq
Actuator
total qty
Face-
to-face
linkage
Linkage
on face
3, 4, 6, 8 13.00 2 18.00 18.00 18.00 1 - 1 2 No No
10, 12 16.00 2 22.50 22.50 22.50 1 - 1 2 No No
14, 17 13.00 4 18.00 18.00 54.00 1 1 1 3 No No
21, 25 16.00 4 22.50 22.50 67.50 1 1 1 3 No No
30, 35, 40 20.00 4 33.00 33.00 99.00 1 1 1 3 No No
50, 57, 66 24.00 4 36.00 36.00 108.00 1 1 1 3 No No
80 28.00 4 37.50 37.50 112.50 1 1 1 3 No No
100 28.00 6 37.50 37.50 187.50 1 1 1 3 No Yes
120 24.00 8 36.00 36.00 252.00 1 1 1 3 No Yes
