Trane CSAA User Manual

Component Installation
70 CLCH-SVX07K-EN
Table 29. Energy recovery recirculation parallel-blade damper
Unit size A (in) B (in)
Damper
qty
Torque
(in-lb.)
Actuator torque
(max) (in-lb.)
Actuator
qty Linkage
3 16.00 13.97 1 10.90 42.00 1 No
4 28.50 13.97 1 19.40 42.00 1 No
6 28.50 13.97 1 19.40 42.00 1 No
8 35.00 13.97 1 23.80 42.00 1 No
10 46.00 13.97 1 31.20 42.00 1 No
12 51.00 13.97 1 34.60 42.00 1 No
14 56.50 13.97 1 38.40 180.00 1 No
17 56.50 13.97 1 38.40 180.00 1 No
21 64.50 13.97 1 43.80 180.00 1 No
25 64.50 13.97 1 43.80 180.00 1 No
30 78.00 13.97 1 53.00 180.00 1 No
35 84.50 13.97 1 57.40 180.00 1 No
40 97.00 13.97 1 65.90 180.00 1 No
50 110.00 13.97 1 74.70 180.00 1 No
Table 30. Face damper torque requirements
Unit size A (in) B (in) Damper Qty Torque (in-lb)
Actuator torque
(max) (in-lb.) Actuator Qty
3 23.20 19.72 1 13.80 42.00 1
4 35.70 19.72 1 21.30 42.00 1
6 35.70 25.47 1 27.50 42.00 1
8 42.20 25.47 1 32.50 42.00 1
10 53.20 25.47 1 40.90 42.00 1
12 58.20 31.22 1 54.90 180.00 1
14 63.70 31.22 1 60.10 180.00 1
17 63.70 36.97 1 71.10 180.00 1
21 71.70 42.72 1 92.50 180.00 1
25 71.70 48.47 1 105.00 180.00 1
30 85.20 48.47 1 124.70 180.00 1
35 43.44 50.94 2 133.70 180.00 1
40 32.19 50.94 3 148.60 180.00 1
50 36.52 62.44 3 206.70 180.00 2
57 36.52 68.19 3 225.70 180.00 2
66 41.52 73.94 3 278.20 180.00 2
80 41.52 85.44 3 321.50 180.00 2
100 46.19 99.41 3 416.10 180.00 3
120 55.35 99.41 3 498.70 180.00 3
