Start-Up
CLCH-SVX07K-EN 139
Fan Size (inches)/Type Fan Class Fan Name K-Factor
32 FC Medium 32 FA 23880.00
32 FC High 32 FB 23587.40
36 FC Medium 36 FA 31600.00
36 FC High 36 FB 31035.70
40 FC Medium 40 FA 38242.00
40 FC High 40 FB 37102.90
10 BC belt-drive plenum Any 10 PA or 10 PB 491.00
11 BC belt-drive plenum Any 11PA or 11 PB 603.30
12 AF belt-drive plenum Any 12PA or 12 PB 1168.70
14 AF belt-drive plenum Any 14PA or 14 PB 1536.10
16 AF belt-drive plenum Any 16PA or 16 PB 1870.00
18 AF belt-drive plenum Any 18PA or 18 PB 2270.70
20 AF belt-drive plenum Any 20PA or 20 PB 2905.20
22 AF belt-drive plenum Any 22PA or 22 PB 3673.20
25 AF belt-drive plenum Any 25PA or 25 PB 4608.20
28 AF belt-drive plenum Any 28 PA or 28 PB 6277.80
32 AF belt-drive plenum Any 32 PA or 32 PB 7847.30
36 AF belt-drive plenum Any 36 PA or 36 PB 10017.80
40 AF belt-drive plenum Any 40 PA or 40 PB 13023.10
44 AF belt-drive plenum Any 44 PA or 44 PB 14692.80
49 AF belt-drive plenum Any 49 PA or 49 PB 17538.00
55 AF belt-drive plenum Any 55 PA or 55 PB 21368.00
63 AF belt-drive plenum Any 63 PA or 63 PB 28100.00
10.50 AF direct-drive plenum Any 10 TF, 10 TR, 10 UF, 10 UR 576.00
12 AF direct-drive plenum Any 12 TF, 12 TR, 12 UF, 12 UR 945.00
13.50 AF direct-drive plenum Any 13 TF, 13 TR, 13 UF, 13 UR 965.00
15 AF direct-drive plenum Any 15 TF, 15 TR, 15 UF, 15 UR 1227.00
16 AF direct-drive plenum Any 16 TF, 16 TR, 16 UF, 16 UR 1519.00
18 AF direct-drive plenum Any 18 TF, 18 TR, 18 UF, 18 UR 1822.00
20 AF direct-drive plenum Any 20 TF, 20 TR, 20 UF, 20 UR 2186.00
22 AF direct-drive plenum Any 22 TF, 22 TR, 22 UF, 20 UR 2714.00
24 AF direct-drive plenum Any 24 TF, 24 TR, 24 UF, 24 UR 3285.00
27 AF direct-drive plenum Any 27 TF, 27 TR, 27 UF, 27 UR 3998.00
30 AF direct-drive plenum Any 30 TF, 30 TR, 30 UF, 30 UR 4945.00
11.00 motorized impeller Any 11 VP, 11 VP, 11 EP 864.00
12.20 motorized impeller Any 12 VP, 12 VP, 12 EP 1078.00
14.00 motorized impeller Any 13 VP, 13, VP, 13 EP 1375.00
15.70 motorized impeller Any 15 VP, 15 VP, 15 EP 1747.00
17.70 motorized impeller Any 17 VP, 17 VP, 17 EP, 17 FP 2231.00
19.70 motorized impeller Any 19VP, 19VP, 19EP, 19FP 2612.00
22.00 motorized impeller Any 22VP, 22VP, 22 EP, 22FP 3233.00
24.80 motorized impeller Any 24VP 4071.00
Note: This table to be used for the updated tap design - mid-2014 and beyond. Refer to prior editions of this publication for the previous design.
Table 51. Constant K factors (continued)
