Component Installation
86
CLCH-SVX07K-EN
Figure 109.Side-loading cartridge fi
lter placement for
unit sizes 40-120
Size 57
24
24
24
24
3.5
24
24
24
24
60.00 ft
²
Size 66
20
24
20
20
20
24
24
24
24
18.5
66.67 ft
²
Size 80
24
24
6.9
24
24
24
24
24
24
24
12
88.00 ft
²
Size 100
12
20
24
1.7
24
24
24
24
24
24
24
24
24
8.9
20
20
20
20
20
20
12
111.33 ft
²
Size 120
24
24
1.2
12
24
24
24
24
24
24
24
24
24
12
12.8
134.00 ft
²
Size 40
24
24
24
2.5
24
24
24
12
36.00 ft
²
Size 50
12
24
24
24
3.5
24
24
24
24
50.00 ft
