Trane CSAA User Manual

Component Installation
CLCH-SVX07K-EN 89
Figure 112.Front-load short bag filter placement for unit sizes 3-35
Size 12
10.88
24
24
24
12 2.13
10.00 ft ²
Size 25
24
24
24
6.75
24 24 3.63
24.00 ft ²
Size 3
2.00 ft ²
12
24
3.38
10.38
Size 4
2.00 ft ²
12
24 15.88
10.38
Size 6
6.00 ft ²
24 12
24
3.75
4.63
Size 8
6.00 ft ²
24
24
10.2512
7.13
Size 10
8.00 ft ²
24
24
9.25
24
7.13
Size 14
10.00 ft ²
24
7.63
24
24 12
10.88
Size 21
18.00 ft ²
12
24
3.63
242424
10
Size 30
28.00 ft ²
6.75
24
24
24
5.0024 24 12
Size 17
14.00 ft ²
12
24
24
24 12
7.63
6.25
Size 35
34.00 ft ²
24
24
24
12
24 2412
11.50
.38
