Control and input elements
Press the button, in order to clamp the tube in the collet of the
off-set bend device. The button must be held until the tube is
clamped.
Chuck open
Press the button to unclamp the tube in the collet of the off-set bend
device. The button must be held until the tube is unclamped.
Manual / Automatic operation mode
0 = Operating of the machine in the manual operating mode.
The release of the functions takes place in inching
(step by step) operation.
1 = Operating of the machine in the automatic operating
mode. The release of the functions take place by
pushing the buttons at the control panel.
Reverence drive / Automatic start
Press the button to start the feference drive of the machine.
Press the button to start the automatic operating cycle.
