Control and input elements
48
Bending, speeds and additiv values
Bending
Input in this table the bending angles of the
individual tubing positions.
Length
Input in this table the length positions of the
individual tubing positions.
Rotation
Input in this table the rotation positions of the
individual tubing positions.
P- Length
Input in this table the speed of the length axle of
the individual tubing positions.
P- Rotation
Input in this table the speed of the rotation axle of
the individual tubing positions.
Rotation
Input in this table the rotating direction of the
individual tubing positions. By setting Auto the
shortest rotating direction is determined
automatically by the control.
P- Bending
Input in this table the speed of the bending axle of
the individual tubing positions.
