Operating
Press Tool plate backward. The tool plate drives back to starting position.
Press Mandrel forward. The machine is in starting position.
Press Clamping forward. The pressure die moves forward and the clamping
die clamps the tube.
Press Bending forward to start the process.
Now the machine will bend the tube in inching-service up to chosen bending
angle is achieved. After bending the machine drives into starting position.
- Outer support backward
- Clamping backward
- Bending backward
Unchuck the tube in the off-set bend device and take the bent tube out of the
machine.
Push the tool plate back to the startposition by hand.
Press Mandrel forward. The machine is in starting position.
Bending process is finished.
