Transfluid DB 2090 ST - Page 93

Operating
93
 Press Clamping forward. The pressure die moves forward and the clamping
die clamps the tube.
 Press Bending forward to start the process. Now the machine will bend the
tube in inching-service up to chosen bending angle is achieved. After bending
the machine drives into start position.
- Outer support backward
- Clamping backward
- Bending backward
 Move the off-set bend device to the next rotation and length position.
