UniVer TC User Manual

Rev.B15
Pg. 56 di 80
From the master configuration programme it is possible to enable or disable the creation of some errors,
and set some device options.
If the option “Further module diagnostics” is disabled, no module error is generated.
Parameter table
Diag: Main Power Loss
Enable or disable the creation of the diagnostics in case of Power Loss
for outputs (VA24).
Diag: Module Fail
Enable of disable the creation of the diagnostics in case of module
failure
Diag: Output Fail
Enable or disable the creation of the diagnostics in case of overload or
short circuit of the outputs.
Diag: High Noise Level
Enable or disable the creation of the diagnostics in case of high noise
level.
Diag: Input Power Loss
Enable or disable the creation of the diagnostics in case of Input power
loss.
Sample Rate
Slow: Environment Input filter very disturbed (> 50mS).
Fast: Max. input sampling rate (< 50mS).
The response time depends on the number of inputs and outputs of the
system.
Default: Slow.
Mode Manifold First
If True, the integrated manifold will use the first 3 bytes of the
allocated address.
If False, the integrated manifold will use the last 3 bytes of the
allocated address.
Fault Action Option
Select the desired behaviour in case of master CPU STOP.
“Turn Output Off” if you want to turn off automatically all the
outputs.
“Keep Last Value” if you want to keep all the outputs as they were in
the latest status.
(in that case pay attention to the dangerous conditions that may be
generated in the system).
Default: “Turn Output Off”.
Extended Module Diag If enabled, a diagnostics for each extended module will be created.
Diag: Electric Clamp Fail
Enable or disable the creation of a diagnostics in case of error by the
electric power clamp (FAIL output of the power clamp activated).
Diag: Electric Clamp command
Fail
Enable or disable the creation of a diagnostics in case of overload or
short circuit on one or more command output of the electric clamp.
Electric Clamp Lag Time
Delay time between the control of one power clamp and the following
one (25…400mS in steps of 25mS).
Default: 150mS.
Simultaneous Electric Clamp
Number of power clamps that may be activated in the same moment
(1…8).
Default 8.
Note: if not configured, all the functions are enabled.
The procedure to modify the configuration paramenters depends on the used master software.
In the following page you can see an example of the many shown in “Online Parameters” of “Applicom
Consolle”.
