2AV/X
1-1-2
1-1
Transfer system ............................. Transfer roller
Fixing system ................................. Heat roller
Heat source: halogen heaters (850 W for 120 V specifications/910 W for 220-240 V
specifications)
Control temperature: 180°C/356°F (at normal ambient temperature)
Abnormally high temperature protection device: 140°C/284°F thermostat
Fixing pressure: 49 N
Charge erasing system .................. Exposure by cleaning lamp
Cleaning system............................. Cleaning blade
Scanning system ............................ Flat bed scanning by CCD image sensor
Resolution ...................................... 600 × 600 dpi
Light source.................................... Inert gas lamp
Dimensions .................................... 550 (W) × 560 (D) × 455 (H) mm
21
5
/
8
" (W) × 22
1
/
16
" (D) × 17
15
/
16
" (H)
550 (W) × 560 (D) × 498 (H) mm (for Asia and Oceania specifications)
Weight ............................................ Approx. 38 kg/83.6 lbs
41 kg/90.2lbs (for Asia and Oceania specifications)
Floor requirements ......................... 891 (W) × 560 (D) mm
35
1
/
16
" (W) × 22
1
/
16
" (D)
Functions........................................ Self-diagnostics, preheat, automatic copy density control, original size detection*,
automatic paper selection, automatic magnification selection, enlargement/reduction
copy, photo mode and department control
*Optional original size detection sensor is needed for 220-240 V specifications.
Power source ................................. 120 V AC, 60 Hz, 9 A
220 – 240 V AC, 50/60 Hz, 2.8 A
Power consumption........................ 1080 W (120V)
1080W (220 – 240V)
Options ........................................... STDF, drawer, job separator, original cover*, key counter, key card**, memory board,
printer network board
*Standard for Asia and Oceania specifications.
**Optional for 120 V specifications only.
To Next Page
