Utax CD 1020 User Manual

1-1
2AV/X
1-1-5
1-1-2 Parts names and their functions
(1) Copier
Figure 1-1-1
1
2
3
4
5
6
7
8
9
0
!
@
#
$
%
^
&
*
(
)
⁄
¤
‹
‹
›
1 Original cover (optional)*
1
2 Operation panel
3 Paper conveying unit
4 Multi-Bypass
5 Insert guides
6 Support tray
7 Toner cartridge
8 Toner cartridge release lever
9 Waste toner tank
0 Waste toner tank release lever
! Cleaning shaft
@ Front cover
# Main switch
$ Copy store section
% Ejection section
^ Upper drawer
& Lower drawer*
2
* Platen
( Original size scales
) Length adjustment plate
⁄ Width adjustment lever
¤ Drawer lift
‹ Handles for transport
› Lower drawer left cover*
2
*1: Standard for Asia and Oceania specifications
for the 15 cpm copier.
*2: Optional for 15 cpm copier.
