Utax CD 1020 - Machine Cross Section

2AV/X
1-1-8
1-1
1-1-3 Machine cross section
1
5
8
6
7
2
4
3
Light path
Paper path
Figure 1-1-4 Machine cross section
1 Paper feed section
2 Main charging section
3 Optical section
4 Developing section
5 Transfer and paper conveying section
6 Cleaning section
7 Charge erasing section
8 Fixing section
