Utax CD 1020 User Manual

2AV/X
2-4-11
2-4
Maintenance parts list
Maintenance part name
Part No. Fig. No. Ref. No.
Name used in service manual Name used in parts list
Right registration roller RIGHT ROLLER, REGISTRATION 2AV06060 6 8
Left registration roller LEFT ROLLER, REGISTRATION 2AV06070 7 6
Upper paper feed pulley PULLEY, PAPER FEED 2AV06010 6 3
Lower paper feed pulley PULLEY, PAPER FEED 2AV06010 5 30
Bypass paper feed pulley PULLEY, PAPER FEED 2AV06320 6 44
Left registration cleaner assembly PARTS, ASS’Y LEFT REGISTRATION CLEANER,SP 2AV93010 7 25
Right registration cleaner assembly PARTS, ASS’Y RIGHT REGISTRATION CLEANER,SP 2AV93020 6 42
Left cover COVER, CONVEYING 2AV04120 7 2
Contact glass CONTACT GLASS 35912010 9 46
Slit glass CONTACT GLASS, ADF 2AV12250 9 19
Mirror 1 MIRROR A 2AV12150 9 9
Mirror 2 and mirror 3 MIRROR B 2AV12160 9 10
Exposure lamp LAMP, SCANNER 2AV12100 9 4
Original size detection sensor SENSOR, ORIGINAL DETECTION 35927290 9 53
Cleaning blade BLADE, CLEANING 2AV18030 11 6
Drum separation claw CLAW, SEPARATION 2AR18240 11 112
Drum shaft SHAFT, DRUM 2AR08030 11 23
Drum shaft front bushing FRONT BUSHING, DRUM SHAFT 2AR09230 11 32
Cleaning lower seal A LOWER SEAL A, CLEANING 2AR93410 11 94
Drum SET, DRUM 2AV82010 11 1
Charger assembly MAIN CHARGER ASS’Y A 2AR93420 11 12
Cleaning lamp LAMP, CLEANING LAMP 2AR27031 10 12
Transfer roller assembly PARTS, ASS’Y TRANSFER ROLLER, SP 2AV93030 7 26
Doctor blade cover COVER A DOCTOR BLADE ASS’Y 2AR68580 11 70
Heat roller ROLLER, HEAT 2AV20100 12 12
Press roller PARTS, ROLLER PRESSURE,SP 2AB93040 12 28
Bushing BUSHING, HEAT ROLLER 35920350 12 41
Bearing BEARING, PRESSURE 35920130 12 37
Fixing unit thermister THERMISTOR, FIXING 2AV20250 12 24
Heat roller separation claw CLAW, SEPARATION 35920150 12 39
Fixing heater HEATER 120, FIXING 2AV20130 12 13
Fixing heater HEATER 230, FIXING 2AV20140 12 13
Gear GEAR 35, HEAT ROLLER 35920240 12 40
Eject roller ROLLER, EJECT 2AV20150 12 14
Eject pulley PULLEY, EJECT 2AV20160 12 15
• Copier
• Optional drawer
Maintenance part name
Part No. Fig. No. Ref. No.
Name used in service manual Name used in parts list
Paper feed pulleys PULLEY, PAPER FEED 2AV06010 2 30
Conveying roller ROLLER,CONVEYING 3A506060 2 23
