2AV/X
2-3-3
Terminals (CN) Voltage Remarks
2-3
TB-1 TB-2 120 V AC 120 V AC supply, input
TB-1 TB-2 220-240 V AC 220-240 V AC supply, input*
2
TB-4 TB-5 120 V AC 120 V AC supply for MSW, output
TB-4 TB-5 220-240 V AC 220-240 V AC supply for MSW, output*
2
2-3 2-1 120 V AC AC supply for FH, output
2-3 2-1 220-240 V AC AC supply for FH, output*
2
3-1, 2 3-3, 4 24 V DC 24 V DC supply for MPCB, output
3-5, 6 3-7, 8 5.1 V DC 5.1 V DC supply for MPCB, output
3-9 3-10 3.3 V DC 3.3 V DC supply for MPCB, output
4-1 3-3 0/5 V DC FH on/off, input
4-3 4-2 12 V DC 12 V DC supply for MPCB, output
5-2 5-1 120 V AC 120 V AC supply for drawer heater*
1
(DH), output
5-2 5-1 220-240 V AC 220-240 V AC supply for drawer heater*
1
(DH), output*
2
*1: Optional. *2: For 220-240 V specifications.
