2-4
2AV/X
2-4-3
Timing chart No. 3 Copying an A5R/5
1
/2" × 8
1
/2" original onto a sheet of A3/11" × 17" copy paper from the bypass tray, magnification ratio 200%
Start key
Any key
SM
DM
RCL
BYPPFCL
MC REM
CL
RSW
ESW
TC REM
DB REM
CN28-1,3,4,6
CN12-16
CN4-10
CN4-12
CN4-3
CN12-2
CN3-7
CN12-6
CN4-5
CN4-4
2834 P 2834 P 2834 P 2362 P
1078 P
34 P
5136 P 4024 P
472 P
178 ms
3000 ms
500 ms
100 ms
263 ms
418 ms 474 ms
300 ms
840 ms
30 s
1316 ms
Fwd. rotation
Rev. rotation
