1-3-11
2AV/X
1-3
Install a toner cartridge.
1. Open the front cover.
2. Shift the toner cartridge release lever to the right
until it stops.
3. Tap the toner cartridge on the top five or six times
and shake it horizontally eight to ten times to
agitate the toner.
4. Align the arrows on the top of the toner cartridge
with the cutouts in the eject tray and then insert
the cartridge into the copier.
5. Secure the toner cartridge by shifting the toner
cartridge release lever to the left until it stops.
6. Close the front cover.
Figure 1-3-16
Figure 1-3-17
Figure 1-3-18
Toner cartridge release lever
Toner cartridge
Cutouts
To Next Page
