1-4-49
2AV/X
Description
Maintenance
item No.
1-4
U906 Resetting partial operation control
Description
Resets the service call code for partial operation control.
Purpose
To be reset after partial operation is performed due to problems in the drawers or other sections, and the
related parts are serviced.
Method
1. Press the start key.
2. Select EXECUTE using the cursor up/down keys.
3. Press the start key to reset partial operation control. The maintenance mode is exited, and the machine
returns to the same status as when the main switch is turned on.
U908 Changing the total counter value
Description
Displays, clears and changes the total counter value.
Purpose
To check the total counter value.
Method
1. Press the start key. The total counter value is displayed.
Clear
1. Select CANCEL using the cursor up/down keys.
2. Press the start key. The value is cleared.
Setting
1. Enter a six-digit value using the numeric keys.
2. Press the start key. The value is set.
Completion
To exit this maintenance item without changing the current total counter value, press the stop/clear key. The
screen for selecting a maintenance item No. is displayed.
U910 Clearing the black ratio data
Description
Clears the accumulated black ratio data for A4 sheets.
Purpose
To clear data as required at times such as during maintenance service.
Method
1. Press the start key. The screen for selecting an item is displayed.
2. Select EXECUTE using the cursor up/down keys.
Do not clear the black ratio data
Clears the black ratio data
Display
CANCEL
EXECUTE
Description
3. Press the start key. The accumulated black ratio data is cleared, and the screen for selecting a
maintenance item is displayed.
Completion
To exit this maintenance item without changing the current setting, press the stop/clear key. The screen for
selecting a maintenance item is displayed.
