Vacon 100 flow Installation Manual

2 SAFETY
2.1 THE SAFETY SYMBOLS USED IN THE MANUAL
This manual contains warnings and cautions, which are identified with safety symbols. The
warnings and cautions give important information on how to prevent injury and damage to
the equipment or your system.
Read the warnings and cautions carefully and obey their instructions.
Table 1: The safety symbols
The safety symbol The safety word Description
WARNING!
If you do not obey the
instructions, injury or
death is possible.
CAUTION!
If you do not obey the
instructions, damage to
the equipment is possible.
HOT SURFACE!
If you do not obey the
instructions, burns are
possible.
2.2 WARNING
WARNING!
Do not touch the components of the power unit when the drive is connected to
mains. The components are live when the drive is connected to mains. A contact
with this voltage is very dangerous.
WARNING!
Do not touch the motor cable terminals U, V, W, the brake resistor terminals or the
DC terminals when the drive is connected to mains. These terminals are live when
the drive is connected to mains, also when the motor does not operate.
WARNING!
Do not touch the control terminals. They can have a dangerous voltage also when
the drive is disconnected from mains.
VACON · 10 SAFETY
2
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
