3.2 TYPE DESIGNATION CODE
The type designation code is made of standard codes and option codes. Each part of the type
designation code agrees to the data in your order. The code can have this format, for
example:
VACON0100-3L-0385-5-FLOW+IP00
Table 3: The description of the parts in the type designation code
Code Description
VACON0100 The product family: VACON0100 = the VACON
®
100 product family
3L Input/Function: 3L = A 3-phase input
0385 The drive rating in amperes. For example, 0385 = 385 A
5 The mains voltage:
2 = 208-240 V
5 = 380-500 V
7 = 525-690 V
FLOW The product:
(empty) = The VACON
®
100 INDUSTRIAL AC drive
FLOW = The VACON
®
100 FLOW AC drive
+IP00 The enclosure class of the AC drive is IP00.
3.3 THE CONTENTS OF THE DELIVERY
The contents of the delivery, MR8-MR9
•
The IP00 drive module with an integrated control unit
•
An accessories bag
•
Installation Manual, Application Manual and manuals for the options that you ordered
The contents of the delivery, MR10
•
The IP00 drive module with an integrated control unit
•
An accessories bag
•
The options module, if you ordered it with options
•
Installation Manual, Application Manual and manuals for the options that you ordered
The contents of the delivery, MR12
•
The IP00 drive module: 2 power units, 1 of them with an integrated control unit
•
An accessories bag
•
The options module, if you ordered it with options
•
A DC link cable
•
A set of optical fibre cables
•
Installation Manual, Application Manual and manuals for the options that you ordered
RECEIVING THE DELIVERY VACON · 15
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
3
