Vacon 100 flow Installation Manual

PREFACE
DOCUMENT DETAILS
Document ID: DPD01665D
Date: 6.11.2017
ABOUT THIS MANUAL
This manual is copyright of VACON Ltd. All Rights Reserved. The manual is subject to change
without prior notice. The language of the original instructions is English.
ABOUT THE PRODUCT
This manual describes the VACON
®
100 IP00 Drive Module. The drive has a power range of
75-800 kW, and a voltage range of 208-240 V, 380-500 V, or 525-690 V. The drive is available in
4 different enclosure sizes: MR8, MR9, MR10 and MR12. The enclosure class of the drive is
IP00, and that is why the drive must be installed in a cabinet or other enclosure after
delivery.
Fig. 1: Examples of the VACON
®
100 IP00 drive module
PREFACE VACON · 3
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
