Vacon 100 flow - Dimensions for Flange Mounting of MR9

4.5 DIMENSIONS FOR FLANGE MOUNTING OF MR9
1060 (41.73)
397.5 (15.65)
550 (21.65) 525 (20.67)
108
(4.25)
255.8 (10.07)
247 (9.72)
M8
GND
72
(2.83)
102 (4.02)
73 (2.87)
175
(6.89)
175
(6.89)
85
(3.35)
10.5
(0.41)
163
(6.42)
300 (11.81)
300 (11.81)
1039 (40.90)
10.5 (0.41)
56 (2.20)
75 (2.95)
Ø22
(0.87)
210 (8.27)
Ø25
(0.98)
42 (1.65)
120 (4.72)
449 (17.68)
108.5 (4.27)
Ø6.5
126 (4.96)
Fig. 8: The dimensions of the AC drive, flange mounting, MR9 [mm (in)]
VACON · 26 MOUNTING DIMENSIONS
