4.4 DIMENSIONS FOR FLANGE MOUNTING OF MR8
359 (14.13) 326 (12.83)
6.8
(0.27)
424.7 (16.72)
89.6
(3.53)
890.8 (35.07)
233 (9.17)
831.5 (32.74)
315.5 (12.42)
19.4
(0.76)
852.6 (33.57)
573.5 (22.58)
82.5
(3.25)
26
(1.02)
182.5 (7.18) 334 (13.15)
72 (2.83)
898 (35.35)
102 (4.02)
GND M8
293 (11.53)
109.5
(4.31)
1.9
(0.07)
Ø7 (0.28)
Ø6.5
(0.26)
Ø7 (0.28)
Ø7 (0.28)
Fig. 7: The dimensions of the AC drive, flange mounting, MR8 [mm (in)]
MOUNTING DIMENSIONS VACON · 25
