Vacon 100 flow Installation Manual

9.1.3 MAINS VOLTAGE 525-690 V
Table 36: The power ratings of VACON
®
100 INDUSTRIAL in mains voltage 525-690 V, 50-60 Hz,
3~
Enclos
ure
size
Drive
type
Loadability Motor shaft power
Low High Max
curre
nt I
s
2s
600 V mains 690 V mains
Contin
uous
curre
nt
I
Lout
[A]
Input
curre
nt I
Lin
[A]
10%
over-
load
curre
nt [A]
Contin
uous
curre
nt
I
Hout
[A]
Input
curre
nt I
Hin
[A]
50%
over-
load
curre
nt [A]
10%
over-
load
40°C
[Hp]
50%
over-
load
40°C
[Hp]
10%
over-
load
40°C
[kW]
50%
over-
load
40°C
[kW]
MR8 0080 80.0 90.0 88.0 62.0 72.0 93.0 124.0 75.0 60.0 75.0 55.0
0100 100.0 106.0 110.0 80.0 89.0 120.0 160.0 100.0 75.0 90.0 75.0
0125 125.0 127.0 137.5 100.0 104.0 150.0 200.0 125.0 100.0 110.0 90.0
MR9 0144 144.0 156.0 158.4 125.0 140.0 187.5 250.0 150.0 125.0 132.0 110.0
0170 170.0 179.0 187.0 144.0 155.0 216.0 288.0 - - 160.0 132.0
0208 208.0 212.0 228.8 170.0 177.0 255.0 340.0 200.0 150.0 200.0 160.0
MR10 0261 261.0 272.0 287.1 208.0 223.0 312.0 416.0 250.0 200.0 250.0 200.0
0325 325.0 330.0 357.5 261.0 269.0 391.5 522.0 300.0 250.0 315.0 250.0
0385 385.0 386.0 423.5 325.0 327.0 487.5 650.0 400.0 300.0 355.0 315.0
0416* 416.0 415.0 457.6 385.0 382.0 577.5 770.0 450.0 300.0 400.0 355.0
MR12 0460 460.0 477.0 506.0 416.0 433.0 624.0 832.0 450.0 400.0 450.0 400.0
0520 520.0 532.0 572.0 460.0 472.0 690.0 920.0 500.0 450.0 500.0 450.0
0590 590.0 597.0 649.0 520.0 527.0 780.0 1040.0 600.0 500.0 560.0 500.0
0650 650.0 653.0 715.0 590.0 591.0 885.0 1180.0 650.0 600.0 630.0 560.0
0750* 750.0 747.0 825.0 650.0 646.0 975.0 1300.0 700.0 650.0 710.0 630.0
0820* 820.0 813.0 902.0 650.0 739.0 975.0 1300.0 800.0 650.0 800.0 630.0
9.1.4 OVERLOAD CAPABILITY
The low overload means that if 110% of the continuous current (I
L
) is required for 1 minute
every 10 minutes, the remaining 9 minutes must be approximately 98% of I
L
or less. This is to
make sure that the output current is not more than I
L
during the duty cycle.
TECHNICAL DATA, VACON® 100 INDUSTRIAL VACON · 105
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
9

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
