Vacon 100 flow Installation Manual

Table 47: The technical data of the VACON
®
100 FLOW AC drive
Technical item or function Technical data
Control characteristics
Switching frequency (see
parameter P3.1.2.3)
200-500 V
•
MR8-MR12:
•
1.5-6 kHz
•
Default: MR8: 3 kHz, MR9: 2 kHz, MR10: 2
kHz, MR12: 2 kHz
690 V
•
MR8-MR12:
•
1.5-6 kHz
•
Default: 2 kHz
•
For a product that is configured for a C4
installation on IT network the maximum
switching frequency is limited to default
2kHz.
Automatic switching frequency derating in case of
overload.
Frequency reference:
Analogue input
Panel reference
Resolution 0.1% (10-bit), accuracy ±1%
Resolution 0.01 Hz
Field weakening point 8-320 Hz
Acceleration time 0.1-3000 s
Deceleration time 0.1-3000 s
VACON · 120 TECHNICAL DATA, VACON® 100 FLOW
10
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
