Vacon 100 flow Installation Manual

Table 16: Drive fuses, 525-690 V, Bussmann
Enclosure
size
Type I
L
[A] Catalogue number of the
fuse
Fuse
rating
[A]
Number
of fuses
needed
Fuse
size
Minimum
prospective
short
circuit
current
MR8
0080 6
0080 7
80 170M3814D 160 3 1 650
0100 6
0100 7
100 170M3815D 200 3 1 950
0125 6
0125 7
125 170M3816D 250 3 1 1300
MR9
0144 6
0144 7
144 170M3817D 315 3 1 1700
0170 6
0170 7
170 170M3819D 400 3 1 2400
0208 6
0208 7
208 170M4863D 450 3 1 2800
MR10
0261 6
0261 7
261 170M5811D 550 3 2 3400
0325 6
0325 7
325 170M5813D 700 3 2 4800
0385 6
0385 7
385 170M5814D 800 3 2 5750
0416 6
0416 7
416 170M6814D 1000 3 3 7500
MR12
0460 6
0460 7
460 170M5811D 550 6 2 3400
0520 6
0520 7
520 170M5812D 630 6 2 4000
0590 6
0590 7
590 170M5813D 700 6 2 4800
0650 6
0650 7
650 170M5813D 700 6 2 4800
0750 6
0750 7
750 170M5814D 800 6 2 5750
0820 6
0820 7
820 170M6813D 900 6 3 6000
POWER CABLING VACON · 51
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
6

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
