GUID-40C04E99-5E53-44F5-9AC7-7EF0D90DFD70
1. Selector for the predefined factory/user settings
2. Factory setting for slow output and floating position for auxiliary hydraulics
valves
3. Factory setting for medium output
4. Factory setting for maximum output
5. Memory positions for predefined user settings
In the slow output setting, the floating position must be activated using the
joystick or valve control lever.
In the factory settings, the maximum flow of all ports is limited to a fixed value:
• Slow output 10%
• Medium output 50%
• Maximum output 100%
You cannot change any values in the factory settings.
• To select one of the three predefined factory settings, turn the selector to one
of the three factory defined positions.
• To select one of the four predefined user settings, turn the selector to one of
the positions M1, M2, M3 or
.
The position U-pilot holds 30 memory positions for U-pilot programs, which
can also be used just to save predefined settings for auxiliary hydraulic
valves. Then the U-pilot memory position must be selected from the U-pilot
view on the armrest display.
3. Operation
- 212 -
