Symbol Operation Switch positions when
running a programme
Limitation
Hydraulic valve, floating
position activated.
NOTE: The valve number
and port are displayed on
the symbol top left
corner.
Hydraulics activated.
1), 2), 3)
Hydraulic valve, timed
duration position lock
activated.
NOTE: The valve number
and port are displayed on
the symbol top left
corner.
Hydraulics activated.
1), 2), 3)
Front power take-off
(PTO) engaged.
Front PTO disengaged.
Rear PTO engaged.
Rear PTO disengaged.
Driving speed cruise
control 1 activated.
2)
Driving speed cruise
control 2 activated.
2)
Driving speed cruise
control deactivated.
2)
Engine speed cruise
control 1 activated.
2)
Engine speed cruise
control deactivated.
2)
Powershift gear 1
4)
Powershift gear 2
4)
Powershift gear 3
4)
Powershift gear 4
4)
Powershift gear 5
4)
Four-wheel drive (4WD)
engaged.
4)
4WD disengaged.
4)
Differential lock engaged.
4)
Differential lock
disengaged.
4)
Current socket activated.
1)
