12. Start the calibrating procedure by pressing OK.
The tractor automatically selects the optimal gear and engine speed for
calibration. The tractor accelerates to the calibrating speed and the engine
speed rises to the optimal level of 1700 rpm.
13. Calibration starts when the driving speed is suitable for calibrating.
Forward arrows indicate that the calibration is in process.
20
905
2
SET
1
2
3
Running...543
GUID-E069424D-4E16-4D82-8C4B-4ACC221A4BAD
In order for the calibration to proceed normally, the speed should stabilise
within 7 seconds.
14. Let the tractor drive forward until the display shows the calibration result.
• If the calibration is completed successfully, the following view is
displayed:
20
905
2
SET
1
2
3
Calibration OK
GUID-172870FC-E314-4996-9FE8-2768A44C81FE
• If the calibration cannot be completed successfully, the following view is
displayed:
20
905
2
SET
1
2
3
Calibration failed
GUID-D11A6245-2BC0-4CCE-BCD2-DD50599CDF95
When the calibration is completed, the engine speed lowers to low idling
speed.
4. Maintenance
- 378 -
