GUID-354237EC-2DE8-4CC4-9EFD-94F1A0F0A031
1. Engine oil pressure
2. Stop light (is flashing)
3. Gearbox oil pressure
4. Four-wheel drive
5. Parking brake
6. Battery charging
1. Apply the parking brake.
2. Turn the hand throttle to the low idling position.
3. Ensure that the control stop (optional equipment) is deactivated.
4. Press down the clutch pedal.
5. Turn the main power/ignition switch to the power on position.
6. Wait until the glow indicator light
on the instrument panel has gone out.
7. Turn the ignition switch to the starting position.
• When the engine starts to fire up, keep the ignition switch in the starting
position until the engine has started.
• If the engine fails to start within 10 seconds, stop starting and try again.
8. Release the ignition switch when the engine starts.
When the engine starts, the following indicator lights go out:
• Engine oil pressure
• Gearbox oil pressure
• Stop light
• Battery charging
3. Operation
- 73 -
